LNBH21PDT-R

set up converter, monolithic voltage regulator, interface IC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.50~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.50~2.00

PartNumber:: LNBH21PDT-R

Brand:: STMicroelectronics - ST | Pack: HSOP | D/C: 07+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Nemo's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-03-14

From Other Seller

Part Number:LNBH21PDT-R
US $1.50 - 2.00
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

Intended for analog and digital satellite STB receivers/SatTV, sets/PC cards, the LNBH21PDT-R is a monolithic voltage regulator and interface IC, assembled in POWER SO-20, specifically designed to provide the 13/18V power supply and the 22KHz tone signalling to the LNB downconverter in the antenna or to the multiswitch box. In this application field, it offers a complete solution with extremely low component count, low power dissipation together with simple design and I2CTM standard interfacing.

Parametrics

Absolute maximum ratings:(1)DC Input Voltage, VCC: -0.3 to 16V; (2)DC Input Voltage, VUP: -0.3 to 25V; (3)Output Current, IO: Internally Limited VmA; (4)DC Output Pins Voltage, VOTX/RX: -0.3 to 25V; (5)Logic Input Voltage (SDA, SCL, DSQIN, ISEL), VI: -0.3 to 7V; (6)Detector Input Signal Amplitude, VDETIN: -0.3 to 2VPP; (7)Logic High Output Voltage (DSQOUT), VOH: -0.3 to 7V; (8)Gate Current, IGATE: ±400mA; (9)Current Sense Voltage, VSENSE: -0.3 to 1V; (10)Address Pin Voltage, VADDRESS: -0.3 to 7V; (11)Storage Temperature Range, Tstg: -40 to +150℃; (12)Operating Junction Temperature Range, Top: 40 to +125℃.

Features

Features:(1)complete interface betweenLNB and I2CTM bus; (2)built-in DC/DC controller for single 12V supply operation and high efficiency ; (3)two selectable output current limit (450mA / 750mA); (4)both compliant with eutelsat and direct output voltage; (5)accurate built-in 22khz tone oscillator suits widely accepted standards; (6)fast oscillator start-up facilitates DiSEqCTM encoding; (7)built-in 22KHz tone detector supports bi-directional DiSEqCTM2.0; (8)semi-lowdrop post regulator and high efficiency step-up PWM for low power loss: Typ. 0.56W @ 125mA; (9)two output pins suitable to bypass; (10)the output r-l filter and avoid any tone distorsion; (11)cable length digital compensation; (12)overload and over-temperature internal protections.
