Product Summary
The TMS320F2811PBKQ device, members of the TMS320C28x DSP generation, are highly integrated, high-performance solutions for demanding control applications. The functional blocks and the memory maps are described in Section 3, Functional Overview. Throughout this document, TMS320F2811 is abbreviated as F2810, F2811, and F2812, respectively. F281x denotes all three Flash devices. TMS320C2811 is also abbreviated as C2811. C281x denotes all three ROM devices. 2811 denotes both F2811 and C2811 devices.
Parametrics
Absolute maximum ratings:(1)Supply voltage range, VDDIO, VDDA1 , VDDA2 , VDDAIO , and AVDDREFBG: - 0.3 V to 4.6 V ; (2)Supply voltage range, VDD, VDD1: - 0.5 V to 2.5 V ; (3)VDD3VFLrange: -0.3 V to 4.6 V ; (4)Input voltage range, VIN: - 0.3 V to 4.6 V ; (5)Output voltage range, VO: - 0.3 V to 4.6 V ; (6)Input clamp current, IIK(VIN < 0 or VIN > V DDIO ): + 20 mA ; (7)Output clamp current, IOK(VO < 0 or VO > VDDIO ): 20 mA ; (8)Operating ambient temperature ranges, TA:A version (GHH, PGF, PBK): -40C to 85℃; (9)Operating ambient temperature ranges, TA:S version (GHH, PGF, PBK): -40C to 125℃; (10)Operating ambient temperature ranges, TA:Q version (GHH, PGF, PBK): -40C to 125℃; (11)Storage temperature range, Tstg+: -65C to 150℃.
Features
Features:(1)High-Performance Static CMOS Technology; (2)JTAG Boundary Scan Support High-Performance 32-Bit CPU (TMS320C28x); (3)On-Chip Memory; (4)Boot ROM (4K x 16); (5)External Interface (2812); (6)Clock and System Control; (7)Peripheral Interrupt Expansion (PIE) Block That Supports 45 Peripheral Interrupts; (8)Three 32-Bit CPU-Timers; (9)128-Bit Security Key/Lock; (10)Motor Control Peripherals; (11)12-Bit ADC, 16 Channels; (12)Up to 56 General Purpose I/O (GPIO) Pins ; (13)Advanced Emulation Features; (14)Development Tools Include; (15)Low-Power Modes and Power Savings; (16)Package Options; (17)Temperature Options.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TMS320F2811PBKQ |
Texas Instruments |
Digital Signal Processors & Controllers (DSP, DSC) 32-Bit Digital Sig Controller w/Flash |
Data Sheet |
|
|
||||||||||||
